Model No.

SF-2800F14HP

Wattage

2800W

Efficiency

Cybenetics Titanium 230V Input Certified (Overall Efficiency: ≥ 93% to <95%)

Intel Power Design Guide

ATX 12V v2.32, EPS 12V v2.92, ATX 3.1

AC Input | Frequency

Single Voltage 230V | 50 / 60HZ

Fan Size

140mm Double Ball Bearing Cooling Fan

Dimension

200mm(L) x 150mm(W) x 86mm(H)

Protection

OVP、OCP、OPP、SCP、UVP、OTP、LVP、NLO、SLP

Safety

cTÜVus / TÜV / CB / CE / FCC / UKCA / RoHS / KCC / EAC / CQC

Temprature

Passed 50℃ Hot Testing

Cable Spec

20+4Pin

Detachable Cables

one cable (600mm)

(4+4Pin) CPU

two cables (750mm)

PCI-E 6+2Pin

six cables (750mm)

(12+4Pin) VGA

four cables (700mm)

4SATA

four cables (550+110+110+110mm)

4Molex

One cable (550+100+100+100mm)

model no.: SF-2800F14HP

AC INPUT

200-240V 15A 60Hz/50Hz

DC OUTPUT

+3.3V

+5V

+12V

-12V

+5VSB

2800W

Max Output Current

20A

20A

233.3A

0.5A

2.5A

Max Combined Wattage

100W

2799.6W

6W

12.5W

2800W
