Compatibility

   Intel LGA1851/1700/1200/115X

   AMD AM5/AM4

   TDP

   220W

   Overall Dimension

   127×78×152mm (L×W×H)

   Heatsink Material

   4×Ф6mm Heatpipe(HDT)+Aluminum Fin

   Weight

   750g (heatsink+fan)

   Fan Model

   Fan Dimension

   120×120×25mm (1 pc)

   Fan Speed

    500 ~ 2000±10% RPM

   Max. Air Flow

    78.25CFM

   Max. Static Pressure

    2.68mmH2O

   Noise

    29.85dB(A) Max.

   Rated Voltage

   12VDC

   Operating Voltage

   10.8 ～ 13.2VDC

   Started Voltage

   7VDC

   Rated Current

   0.25A

   Power Input

   3W

   Bearing Type

   FDB

   Connector

   4Pin PWM

   EAN

   6931393308173
